AD698APZ ,Active Chip - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

231 points

Part No

AD698APZ
Manufacturer

ADI
ChipWorker Part#

CW112459
Category

Active Chip
Package

PLCC-28
Description

ANALOG DEVICES AD698APZ Signal Conditioner, 20kHz, 13V, 36V, LCC, 28Pins, -40℃
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 25.06

Buy AD698APZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD698APZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD698APZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD698APZ
Manufacturer	ADI
ChipWorker Part#	CW112459
Category	Active Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	PLCC-28
Supply Voltage (DC)	13.0 V, 13.0 V (min)
Output Voltage	24.0 V
Supply Current	15 mA
Number of Positions	28 Position
Bandwidth	20 kHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	13V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	13 V
	expand all
Size-Length	11.58 mm
Size-Width	11.58 mm
Size-Height	3.94 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The AD698APZ is a monolithic Linear Variable Differential Transformer (LVDT) Signal Conditioning Subsystem used in conjunction with LVDTs to convert transducer mechanical position to unipolar or bipolar dc voltage with a high degree of accuracy and repeatability. All circuit functions are included on the chip. With the addition of a few external passive components to set frequency and gain, the AD698 converts the raw LVDT output to a scaled dc signal. The device will operate with half-bridge LVDTs, LVDTs connected in the series opposed configuration (4-wire) and RVDTs. The AD698 contains a low distortion sine wave oscillator to drive the LVDT primary. Two synchronous demodulation channels of the AD698 are used to detect primary and secondary amplitude. The part divides the output of the secondary by the amplitude of the primary and multiplies by a scale factor.
Single chip solution, contains internal oscillator and voltage reference
No adjustments required
Unipolar or bipolar output
Will also decode AC bridge signals
0.05% Linearity

expand all
