Part No

AD7625BCPZ
Manufacturer

ADI
ChipWorker Part#

CW356725
Category

Analog to Digital, ADC IC
Package

LFCSP-32
Description

ANALOG DEVICES AD7625BCPZ ANALOG TO DIGITAL CONVERTER ADC, 16Bit, 6MSPS, LVDS, SERIAL, LFCSP-32
Documentation

Datasheet

AD7625BCPZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD7625BCPZ Specifications

Attribute	Attribute Value

Part Number	AD7625BCPZ
Manufacturer	ADI
ChipWorker Part#	CW356725
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	32 Pin
Case/Package	LFCSP-32
Supply Current	17.0 mA
Number of Circuits	1 Circuit
Number of Positions	32 Position
Number of Bits	16 Bit
Power Dissipation	145 mW
Sample Rate	6 Msps
Power Consumption	145 mW
Resolution (Bits)	16.0 Bit
Number of ADCs	1 ADC
Number of Inputs	1 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	190 mW
Number of Input Channels	1 Channel
	expand all
Size-Length	5 mm
Size-Width	5 mm
Size-Height	0.83 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
HK STC License	NLR

Product Description

Product Details
The AD7625 is a 16-bit, 6 MSPS, charge redistribution successive approximation register (SAR) based architecture analog-to-digital converter (ADC). SAR architecture allows unmatched perfor-mance both in noise (93 dB SNR) and in linearity (1 LSB). The AD7625 contains a high speed, 16-bit sampling ADC, an internal conversion clock, and an internal buffered reference. On the CNV± rising edge, it samples the voltage difference between the IN+ and IN− pins. The voltages on these pins swing in opposite phase between 0 V and REF. The 4.096 V reference voltage, REF, can be generated internally or applied externally.
All converted results are available on a single LVDS self-clocked or echoed-clock serial interface, reducing external hardware connections.
The AD7625 is housed in a 32-lead, 5 mm × 5 mm LFCSP with operation specified from −40°C to +85°C.
