AD9361BBCZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD9361BBCZ
Manufacturer

ADI
ChipWorker Part#

CW683400
Category

RF Module
Package

BGA-144
Description

RF Transceiver IC, 70MHz to 6GHz, 2Bit DAC & ADC, 8 dBm out, 1.267V to 1.33V, BGA-144
Documentation

Datasheet

AD9361BBCZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD9361BBCZ Specifications

Attribute	Attribute Value

Part Number	AD9361BBCZ
Manufacturer	ADI
ChipWorker Part#	CW683400
Category	RF Module
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	144 Pin
Case/Package	BGA-144
Frequency	70MHz ~ 6GHz
Supply Voltage (DC)	1.27V (min)
Number of Positions	144 Position
Output Power	8 dBm
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.3 V
Supply Voltage (Max)	1.33 V
Supply Voltage (Min)	1.267 V
	expand all
Size-Length	10.1 mm
Size-Width	10 mm
Size-Height	1 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	5A991.b
HK STC License	NLR

Product Description

The AD9361BBCZ is a highly integrated 2 x 2 RF Agile Transceiver combines an RF front end with a flexible mixed-signal baseband section and integrated frequency synthesizers, simplifying design-in by providing a configurable digital interface to a processor. Its programmability and wideband capability make it ideal for a broad range of transceiver applications. The device The AD9361 operates in the 70MHz to 6.0GHz range, covering most licensed and unlicensed bands. Channel bandwidths from less than 200kHz to 56MHz are supported.
