ADL5310ACPZ-REEL7 ,Logarithmic Amplifier IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

154 points

Part No

ADL5310ACPZ-REEL7
Manufacturer

ADI
ChipWorker Part#

CW14354359
Category

Logarithmic Amplifier IC
Package

LFCSP-24
Description

120dB RANGE (3nA TO 3mA) Dual Logarithmic Converter
Documentation

Datasheet
Ships from

Moscow
Наличие

110786 pcs In Stock
Estimated Price

$ 7.35

Buy ADL5310ACPZ-REEL7

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADL5310ACPZ-REEL7 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADL5310ACPZ-REEL7 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADL5310ACPZ-REEL7
Manufacturer	ADI
ChipWorker Part#	CW14354359
Category	Logarithmic Amplifier IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	LFCSP-24
Output Current	20mA @5V
Supply Current	9.50 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	24 Position
Power Dissipation	500 mW
Quiescent Current	9.50 mA
Slew Rate	15.0 V/μs
Input Offset Voltage	20 mV
Input Bias Current	400 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	500 mW
Accuracy	0.1 dB
Supply Voltage	3V ~ 12V
Supply Voltage (Max)	10V ~ 15V
	expand all
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

Product Details
The ADL5310 is a low-cost dual logarithmic amplifier that converts input current over a wide dynamic range to a linear-in-dB output voltage. It is optimized for the determination of optical power in wide-ranging optical communication system applications including control circuitry for lasers, optical switches, attenuators, and amplifiers, as well as general system monitoring. The device is equivalent to a dual AD8305 with enhanced dynamic range (120 dB). While the ADL5310 contains two independent signal channels with individually-configurable transfer function constants (slope and intercept), internal bias circuitry is shared between channels for improved power consumption and channel matching. Dual converters in a single compact LFCSP package yield space-efficient solutions for measuring gain or attenuation across optical elements. Only a single supply is required, while optional dual supply operation offers added flexibility.
The ADL5310 employs an optimized translinear structure, which utilizes the accurate logarithmic relationship between a bipolar transistor"s base-emitter voltage and collector current, with appropriate scaling by precision currents to compensate the inherent temperature dependence. Input and reference current pins sink current ranging from 3 nA to 3 mA (limited to ±60 dB between input and reference) into a fixed voltage defined by the VSUM potential, which is internally set to 500 mV but may be externally-grounded for dual-supply operation and additional applications requiring voltage inputs.
### Features and Benefits
Optimized for fiber optic photodiode interfacing
Measures current over 6 decades
Law conformance 0.3 dB from 3 nA to 3 mA
Single- or dual-supply operation (3 V to ±5.5 V total)
Nominal slope of 10 mV/dB (200 mV/decade)
Nominal intercept of 300 pA (set by external resistor)
Optional adjustment of slope and intercept
Full log-ratio capabilities
Temperature stable
Rapid response time for a given current level
Miniature 24-lead chip scale package
(LFCSP 4 mm × 4 mm)
Low power: <10 mA quiescent current
