ADM00398 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADM00398
Manufacturer

Microchip
ChipWorker Part#

CW67217600
Category

Microprocessor Development Kit
Package

Board
Description

ADC Evaluation Board for 16Bit MCUs to evaluate the MCP3911 dual-channel ADC
Documentation

Datasheet

ADM00398 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADM00398 Specifications

Attribute	Attribute Value

Part Number	ADM00398
Manufacturer	Microchip
ChipWorker Part#	CW67217600
Category	Microprocessor Development Kit
Documentation	Datasheet
Case/Package	Board
Number of Bits	8 Bit
Core Architecture	PIC
Core Sub-Architecture	PIC24
	expand all
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The MCP3911 is a MCP3911 ADC evaluation board for 16bit MCUs system provides the ability to evaluate the performance of the MCP3911 dual channel ADC. The MCP3911 is a 2.7V to 3.6V dual channel analog front end containing two synchronous sampling delta sigma analog to digital converters , two PGAs, phase delay compensation block, low drift internal voltage reference, modulator output block, digital offset and gain errors calibration registers, and high speed 20MHz SPI compatible serial interface. It also provides a development platform for 16bit PIC based applications, using existing 100 pin PIM systems compatible with the explorer 16 and other high pin count PIC demo boards. The system comes with a programmed PIC24FJ256GA110 PIM module that communicates with the included PC software for data exchange and ADC configuration.
Dual ADC MCP3911 output display using serial communication to PC software
Simultaneous 55ksps at 95dB SINAD performance on dual MCP3911 channels
Separate power supplies and power planes (4 layer board)
PICtail Plus connectors for explorer 16 daughter board compatibility
Robust hardware design with analog grounding and analog/digital separation
System and ADC performance analysis through graphical PC tools showing noise histogram
