ADM00419 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADM00419
Manufacturer

Microchip
ChipWorker Part#

CW3897600
Category

Microprocessor Development Kit
Package

Module
Description

Processor Extension Pak Board
Documentation

Datasheet

ADM00419 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADM00419 Specifications

Attribute	Attribute Value

Part Number	ADM00419
Manufacturer	Microchip
ChipWorker Part#	CW3897600
Category	Microprocessor Development Kit
Documentation	Datasheet
Case/Package	Module
	expand all
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
HTS Code	8543906800
ECCN Code	EAR99

Product Description

The ADM00419 is a MCP2210 breakout module can be used with either the MCP2210 motherboard or as a standalone USB to SPI (Master) bridge module. The breakout board provides all the signals required to assist the user in building their boards with the MCP2210. The MCP2210 will be detected by a Windows PC host as an HID device. The accompanying software can be used to exercise the MCP2210 breakout module"s features and also provides a reference point for users that want to design their own applications based on the MCP2210 device. The MCP2210 Utility software was created for custom device setting requirements. A few of the settings that this utility can alter include VID, PID, power requirements, and string descriptors. The SPI terminal utility is a tool that allows low level data exchange at the SPI bus level. This application is useful for low level communication and troubleshooting between the MCP2210 and various SPI slave modules.
Small plug-in board with DIP form factor (2 pin, 10 pin headers spaced at 0.6 inches)
Featured with mini USB connector
Access to the SPI bus signals (MOSI, MISO, SCK)
Nine GP lines, configurable for GPIO, chip select or dedicated function operation
PICkit serial analyser compatible header
3.3V or 5V jumper selectable VDD
Able to supply up to 500mA to the rest of the system
