ADT7301ARMZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADT7301ARMZ
Manufacturer

ADI
ChipWorker Part#

CW562529
Category

Temperature Sensor
Package

MSOP-8
Description

ANALOG DEVICES ADT7301ARMZ Temperature Sensor IC, Digital, ± 0.5℃, -40℃, +150℃, MSOP, 8Pins
Documentation

Datasheet

ADT7301ARMZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADT7301ARMZ Specifications

Attribute	Attribute Value

Part Number	ADT7301ARMZ
Manufacturer	ADI
ChipWorker Part#	CW562529
Category	Temperature Sensor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	MSOP-8
Supply Voltage (DC)	2.70V (min)
Output Voltage	400 mV
Supply Current	2.2 mA
Number of Positions	8 Position
Number of Bits	13 Bit
Power Dissipation	1.41 mW
Resolution (Bits)	13.0 Bit
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1.41 mW
Accuracy	±1 ℃
Supply Voltage	2.7V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	2.7 V
	expand all
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The ADT7301 series 13-bit Temperature Monitoring System containing a band gap temperature sensor and a 13-bit ADC to monitor and digitize the temperature reading to a resolution of 0.03125°C. The ADT7301 has a flexible serial interface that allows easy interfacing to most microcontrollers. The interface is compatible with SPI®, QSPI™ and MICROWIRE™ protocols as well as DSPs. The part features a standby mode that is controlled via the serial interface. Shutdown mode that reduces the power consumption to 4.88µW with VDD = 3.3V at 1SPS.
Shutdown current of 1µA
Power dissipation of 0.631mW at VDD = 3.3V
