Part No

ADT7470ARQZ
Manufacturer

ADI
ChipWorker Part#

CW939500
Category

Temperature Sensor
Package

QSOP-16
Description

ANALOG DEVICES ADT7470ARQZ Temperature Sensor IC, Digital, ± 12%, -40℃, +125℃, QSOP, 16Pins
Documentation

Datasheet

ADT7470ARQZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADT7470ARQZ Specifications

Attribute	Attribute Value

Part Number	ADT7470ARQZ
Manufacturer	ADI
ChipWorker Part#	CW939500
Category	Temperature Sensor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	QSOP-16
Frequency	400 kHz
Supply Voltage (DC)	3.00V (min)
Number of Outputs	4 Output
Output Current	≤8.00 mA
Supply Current	0.8 mA
Number of Positions	16 Position
Clock Speed	400 kHz
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±12% (Max)
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	3.91 mm
Size-Height	1.65 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The ADT7470ARQZ is a Temperature Sensor Hub and Fan Controller for systems requiring active cooling. It is designed to interface directly to an I²C® bus. It can monitor up to 10 daisy-chained TMP05 temperature sensors. It can also monitor and control the speed of four fans, in automatic or in manual control loops. A FULL_SPEED input is provided to allow the fans to be blasted to maximum speed, via external hardware control, under extreme thermal conditions or on system start-up. An SMBALERT interrupt communicates error conditions such as fan under speed and over-temperature measurements to the system service processor. Individual error conditions can then be read from status registers over the I²C bus.
Monitors up to 10 remote temperature sensors
Monitors and controls speed of up to 4 fans independently
PWM outputs drive each fan under software control
FULL_SPEED input allows fans to be blasted to maximum speed by external hardware
SMBALERT interrupt signals failures to system controller
Three-state ADDR pin allows up to 3 devices on a single bus
Temperature decoder interprets TMP05 temperature sensors and communicates values over I²C bus
Limit comparison of all monitored values
Supports fast I²C standard (400kHz maximum)
ESD sensitive device, take proper precaution while handling the device.

expand all
