ADXL250AQC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADXL250AQC
Manufacturer

ADI
ChipWorker Part#

CW389529896
Category

Acceleration Sensor, Accelerometer
Description

Accelerometer Dual ±50g 5V 33mV/g to 43mV/g 14Pin CPAK
Documentation

Datasheet

ADXL250AQC Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADXL250AQC Specifications

Attribute	Attribute Value

Part Number	ADXL250AQC
Manufacturer	ADI
ChipWorker Part#	CW389529896
Category	Acceleration Sensor, Accelerometer
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	CPAK
Frequency	24.0 kHz
Supply Voltage (DC)	5.00 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	5 V
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	Non-Compliant
HK STC License	NLR

Product Description

GENERAL DESCRIPTION
The ADXL150 and ADXL250 are third generation ±50 g surface micromachined accelerometers. These improved replacements for the ADXL50 offer lower noise, wider dynamic range, reduced power consumption and improved zero g bias drift. The ADXL150 is a single axis product; the ADXL250 is a fully integrated dual axis accelerometer with signal conditioning on a single monolithic IC, the first of its kind available on the commercial market. The two sensitive axes of the ADXL250 are orthogonal (90°) to each other. Both devices have their sensitive axes in the same plane as the silicon chip.
FEATURES
Complete Acceleration Measurement System on a Single Monolithic IC
80 dB Dynamic Range
Pin Programmable 650 g or 625 g Full Scale
Low Noise: 1 mg/√Hz Typical
Low Power: <2 mA per Axis
Supply Voltages as Low as 4 V
2-Pole Filter On-Chip
Ratiometric Operation
Complete Mechanical & Electrical Self-Test
Dual & Single Axis Versions Available
Surface Mount Package
