ADXL357 - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ADXL357
Manufacturer

ADI
ChipWorker Part#

CW760393503
Description

Low Noise, Low Drift, Low Power, 3-Axis MEMS Accelerometers with Digital Output
Documentation

Datasheet

ADXL357 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADXL357 Specifications

Attribute	Attribute Value

Part Number	ADXL357
Manufacturer	ADI
ChipWorker Part#	CW760393503
Documentation	Datasheet
	expand all
Product Lifecycle Status	Recommended for New Designs

Product Description

Product Details
The analog output ADXL356 and the digital output ADXL357 are low noise density, low 0 _g_ offset drift, low power, 3-axis accelerometers with selectable measurement ranges. The ADXL356B supports the ±10 _g_ and ±20 _g_ ranges, the ADXL356C supports the ±10 _g_ and ±40 g ranges, and the ADXL357 supports the ±10.24 g, ±20.48 g, and ±40.96 g ranges.
The ADXL356/ADXL357 offer industry leading noise, minimal offset drift over temperature, and long-term stability, enabling precision applications with minimal calibration.
Low drift, low noise, and low power ADXL357 enables accurate tilt measurement in an environment with high vibration, such as airborne IMUs. The low noise of the ADXL356 over higher frequencies is ideal for wireless condition monitoring.
The ADXL357 multifunction pin names may be referenced by their relevant function only for either the SPI or I2C interface.
Applications
Inertial measurement units (IMUs)/altitude and heading reference systems (AHRSs)
Platform stabilization systems
Structural health monitoring
Seismic imaging
Tilt sensing
Robotics
Condition monitoring
### Features and Benefits
Hermetic package offers excellent long-term stability
0_ g_ offset vs. temperature (all axes): 0.75 mg/°C maximum
Ultralow noise density (all axes): 80 μg/√Hz
Low power, VSUPPLY (LDO enabled)
Measurement mode: 200 μA
Standby mode: 21 μA
Digital output features
Digital serial peripheral interface (SPI)/I2C interfaces
20-bit analog-to-digital converter (ADC)
Data interpolation routine for synchronous sampling
Programmable high- and low-pass digital filters
Integrated temperature sensor
Voltage range options
VSUPPLY with internal regulators: 2.25 V to 3.6 V
V1P8ANA, V1P8DIG with internal low dropout regulator (LDO) bypassed: 1.8 V typical ± 10%
Operating temperature range: −40°C to +125°C
14-terminal, 6 mm × 6 mm × 2.1 mm, LCC package, 0.26 grams
