Part NoAPT100GN60LDQ4G
-
ManufacturerMicrosemi
-
ChipWorker Part#CW125148582
-
CategoryIGBT Transistor, IGBT Module
-
PackageTO-264-3
-
DescriptionTrans IGBT Chip N-CH 600V 229A 625000mW 3Pin(3+Tab) TO-264
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие40 pcs In Stock
-
