Part No

BTS50301EJAXUMA1
Manufacturer

Infineon
ChipWorker Part#

CW2363193
Category

Power Distribution
Package

PG-DSO-8-43-EP
Description

Power Switch Hi Side 1Out 5A 0.03Ω Automotive 8Pin DSO EP T/R
Documentation

Datasheet

BTS50301EJAXUMA1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

BTS50301EJAXUMA1 Specifications

Attribute	Attribute Value

Part Number	BTS50301EJAXUMA1
Manufacturer	Infineon
ChipWorker Part#	CW2363193
Category	Power Distribution
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	PG-DSO-8-43-EP
Number of Outputs	1 Output
Input Voltage (DC)	28.0 V
Output Current	5 A
Supply Current	3.5 mA
Number of Positions	8 Position
Power Dissipation	1.7 W
Output Current (Max)	5 A
Output Current (Min)	5 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1700 mW
Input Voltage	28 V
	expand all
Size-Length	4.9 mm
Size-Width	3.9 mm
Size-Height	1.45 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The BTS5030-1EJA is a 30mR single channel smart high-side Power Switch providing protective functions and diagnosis. The power transistor is built by an N-channel vertical power MOSFET with charge pump. The device is integrated in Smart6 technology. It is specially designed to drive lamps up to 2 x P21W, as well as LEDs in the harsh automotive environment.
One channel device
Very low stand-by current
3.3 and 5V compatible logic inputs
Optimized electromagnetic compatibility
Logic ground independent from load ground
Very low power DMOS leakage current in OFF state
Green product
AEC qualified
