CA3240EZ ,Operational Amplifier, OP Amp IC - Intersil

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

160 points

Part No

CA3240EZ
Manufacturer

Intersil
ChipWorker Part#

CW31593525
Category

Operational Amplifier, OP Amp IC
Package

DIP-8
Description

Operational Amplifier, Dual, 2 Amplifier, 4.5MHz, 9V/µs, 4V to 36V, DIP, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

5398 pcs In Stock
Estimated Price

$ 6.57

Buy CA3240EZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

CA3240EZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

CA3240EZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	CA3240EZ
Manufacturer	Intersil
ChipWorker Part#	CW31593525
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Supply Voltage (DC)	15.0 V
Output Current	20mA @5V
Supply Current	8 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	70 dB
Bandwidth	4.5 MHz
Slew Rate	9.00 V/μs
Gain Bandwidth Product	4.5 MHz
Thermal Shutdown	No
Input Offset Voltage	5 mV
Input Bias Current	10 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	4.5 MHz
Minimum CMRR Range	70 dB
Supply Voltage	4V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	4 V
	expand all
Size-Length	10.16 mm
Size-Width	7.11 mm
Size-Height	4.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The CA3240EZ is a 4.5MHz Dual BiMOS Operational Amplifier with MOSFET input/bipolar output. The CA3240A is the dual versions of the popular CA3140 series integrated circuit operational amplifiers. They combine the advantages of MOS and bipolar transistors on the same monolithic chip. The gate-protected MOSFET (PMOS) input transistors provide high input impedance and a wide common-mode input voltage range (typically to 0.5V below the negative supply rail). The bipolar output transistors allow a wide output voltage swing and provide a high output current capability.
Internally compensated
MOSFET input stage - Very high input impedance (ZIN) 1.5TR (typical)
Directly replaces industry type 741 in most applications
ESD sensitive device, take proper precaution while handling the device.
