Part No

FDMC7660
Manufacturer

Fairchild
ChipWorker Part#

CW15699096
Category

MOSFET, MOSFET Transistor
Package

PowerTDFN-8
Description

FAIRCHILD SEMICONDUCTOR FDMC7660 MOSFET Transistor, N Channel, 20A, 30V, 0.0018Ω, 10V, 1.7V
Documentation

Datasheet

FDMC7660 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

FDMC7660 Specifications

Attribute	Attribute Value

Part Number	FDMC7660
Manufacturer	Fairchild
ChipWorker Part#	CW15699096
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	PowerTDFN-8
Number of Positions	8 Position
Drain to Source Resistance (on) (Rds)	0.0018 Ω
Polarity	N-Channel
Power Dissipation	2.3 W
Threshold Voltage	1.7 V
Drain to Source Voltage (Vds)	30 V
Continuous Drain Current (Ids)	20.0 A
Input Capacitance (Ciss)	4830pF @15V(Vds)
Input Power (Max)	2.3 W
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2.3W (Ta), 41W (Tc)
	expand all
Size-Length	3.3 mm
Size-Width	3.3 mm
Size-Height	1.05 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

The FDMC7660 is a N-channel MOSFET produced using Fairchild Semiconductor"s advanced PowerTrench® process. It has been especially tailored to minimize the ON-state resistance. It is well suited for load switching applications common in portable battery packs.
