FDME1034CZT - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

FDME1034CZT
Manufacturer

Fairchild
ChipWorker Part#

CW78715193
Category

MOSFET, MOSFET Transistor
Package

MicroFET-6
Description

Trans MOSFET N/P-CH 20V 3.4A/2.6A 6Pin MicroFET T/R
Documentation

Datasheet

FDME1034CZT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

FDME1034CZT Specifications

Attribute	Attribute Value

Part Number	FDME1034CZT
Manufacturer	Fairchild
ChipWorker Part#	CW78715193
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	MicroFET-6
Number of Channels	2 Channel
Number of Positions	6 Position
Drain to Source Resistance (on) (Rds)	0.055 Ω
Polarity	N-Channel, P-Channel
Power Dissipation	1.4 W
Threshold Voltage	700 mV
Drain to Source Voltage (Vds)	20 V
Breakdown Voltage (Drain to Source)	20 V
Continuous Drain Current (Ids)	3.4A/2.6A
Input Capacitance (Ciss)	300pF @10V(Vds)
Input Power (Max)	600 mW
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	1.4 W
	expand all
Size-Length	1.6 mm
Size-Width	1.6 mm
Size-Height	0.5 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Product Description

Mosfet Array N and P-Channel 20V 3.8A, 2.6A 600mW Surface Mount 6-MicroFET (1.6x1.6)
