GBU406 - Diodes

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

GBU406
Manufacturer

Diodes
ChipWorker Part#

CW1194004
Category

Bridge Rectifier
Package

SIP-4
Description

Diode Rectifier Bridge Single 600V 4A 4Pin Case GBU Tube
Documentation

Datasheet

GBU406 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

GBU406 Specifications

Attribute	Attribute Value

Part Number	GBU406
Manufacturer	Diodes
ChipWorker Part#	CW1194004
Category	Bridge Rectifier
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	SIP-4
Forward Voltage	1 V
Forward Current	4 A
Max Forward Surge Current (Ifsm)	150 A
Maximum Forward Voltage (Max)	1V @2A
Forward Current (Max)	4 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
	expand all
Size-Length	22.3 mm
Size-Width	3.56 mm
Size-Height	18.8 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99
HK STC License	NLR

Product Description

If you want to convert an alternating current input into a direct current, then this GBU406 full bridge rectifier from Diodes Zetex is perfect for you! In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This rectifier has a minimum operating temperature of -55 °C and a maximum of 150 °C. It is made in a single configuration.
