IPD042P03L3 G ,MOSFET, MOSFET Transistor - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

100 points

Part No

IPD042P03L3 G
Manufacturer

Infineon
ChipWorker Part#

CW15071103
Category

MOSFET, MOSFET Transistor
Package

TO-252-3
Description

Trans MOSFET P-CH 30V 70A Automotive 3Pin(2+Tab) DPAK
Documentation

Datasheet
Ships from

Moscow
Наличие

2243 pcs In Stock
Estimated Price

$ 1.09

Buy IPD042P03L3 G

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

IPD042P03L3 G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

IPD042P03L3 G Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	IPD042P03L3 G
Manufacturer	Infineon
ChipWorker Part#	CW15071103
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-252-3
Number of Channels	1 Channel
Drain to Source Resistance (on) (Rds)	3.5 mΩ
Polarity	P-Channel
Power Dissipation	150 W
Threshold Voltage	2 V
Drain to Source Voltage (Vds)	30 V
Breakdown Voltage (Drain to Source)	30 V
Rise Time	167 ns
Input Capacitance (Ciss)	12400pF @15V(Vds)
Fall Time	22 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	150W (Tc)
	expand all
Size-Length	6.5 mm
Size-Width	6.22 mm
Size-Height	2.3 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Summary of Features:
Enhancement mode
Avalanche rated
Pb-free lead plating; RoHS compliant
Small Signal packages approved to AEC Q101
