ISL6225CA ,Voltage Regulator - Intersil
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
88 points
-
Part NoISL6225CA
-
ManufacturerIntersil
-
ChipWorker Part#CW96279052
-
CategoryVoltage Regulator
-
PackageSSOP-28
-
DescriptionCurrent Mode PWM Controller 0.9V to 5.5V 8A 28Pin QSOP W
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие9516 pcs In Stock
-
Estimated Price$ 2.2
Payment Methods and Delivery
{{ estimate }}
Buy ISL6225CA
Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.
Real stock check
Best price from distributors
Engineer support
ISL6225CA Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}xx
{{ low_stock_text }}
|
1 |
{{weeks_text}}
|
{{ formatQuantity(priceList.quantity) }}
{{currencySymbol}}{{ ToEffectiveNum(toDisplay(priceList.price, activeCurrency)) }}
{{viewMore}}
|
{{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
{{ low_stock_text }}
|
1 | {{weeks_text}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
|
Chipworker
|
{{noList.partNo}}
{{noList.mfr}}
|
{{stockAvailability}}
{{ search_item }}
|
{{moq}} | 1 | 6 - 8 {{delivery_date}} | {{price_on_request_text}} | {{currencySymbol}}{{UpToFourDecimals(toDisplay(priceCalc, activeCurrency),1)}} |
|
|||||||
{{ apiText }}{{ apiTime }}(UTC+8)
Update Data
Chipworker Certification
11+ years sourcing experience
1000+ russia customers
ISO certified supplier
Support small MOQ
*Photos of Our Actual 800 m² Warehouse
ISL6225CA Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | ISL6225CA | |
| Manufacturer | Intersil | |
| ChipWorker Part# | CW96279052 | |
| Category | Voltage Regulator | |
| Documentation | Datasheet | |
| Mounting Style | Surface Mount | |
| Number of Pins | 28 Pin | |
| Case/Package | SSOP-28 | |
| Supply Voltage (DC) | 3.30V (min) | |
| Number of Outputs | 2 Output | |
| Output Voltage | 0.9V ~ 5.5V | |
| Input Voltage | 5V ~ 24V | |
| expand all | ||
| Operating Temperature | -10℃ ~ 85℃ | |
| Product Lifecycle Status | Unknown | |
| Packaging | Tube | |
| RoHS | Non-Compliant | |
| Lead-Free Status | Contains Lead |
Similar & Replacement Parts
Similar products
Product Description
- The ISL6225 dual PWM controller delivers high efficiency and tight regulation from two voltage regulating synchronous buck DC/DC converters. The ISL6225 PWM power supply controller was designed especially for DDR DRAM, SDRAM, and graphic chipset applications in high performance desknote PCs, notebook PCs, sub-notebook PCs, and PDAs.
- Automatic mode selection of constant-frequency synchronous rectification at heavy load, and hysteretic diode-emulation at light load, assure high efficiency over a wide range of conditions. The hysteretic mode of operation can be disabled separately on each PWM converter if constant-frequency continuous-conduction operation is desired for all load levels. Efficiency is further enhanced by using the lower MOSFET rDS(ON) as the current sense element.
- Features
- • Provides regulated output voltage in the range of 0.9V-5.5V
- - High efficiency over wide load range
- - Synchronous buck converter with hysteretic operation at light load
- - Inhibit Hysteretic mode on one, or both channels
- • Complete DDR memory power solution
- - VTT tracks VDDQ/2
- - VDDQ/2 buffered reference output
- • No current-sense resistor required
- - Uses MOSFET rDS(ON)
- - Optional current-sense resistor for precision overcurrent
- • Under-voltage lock-out on VCC pin
- • Dual input voltage mode operation
- - Operates directly from battery 5V to 24V input
- - Operates from 3.3V or 5V system rail
- - VCC from 5V only
- • Excellent dynamic response
- - Combined voltage feed-forward and average current mode control
- • Power-good signal for each channel
- • 300kHz switching frequency
- - 180° channel to channel phase operation for reduced input ripple when not in DDR mode
- - 0° channel to channel phase operation in DDR mode for reduced channel interference
- - 90° channel to channel phase operation for reduced input ripple in DDR mode when VIN is at GND.
- • Pb-Free Available (RoHS Compliant)
- Applications
- • Mobile PCs
- • PDAs
- • Hand-held portable instruments
