L9638D013TR - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

L9638D013TR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW150769200
Category

Interface IC, Interface Controller
Package

SOIC-8
Description

L9638 Series 26V 20 kbaud SMT Single Wire LIN Bus Transceiver - SOIC-8
Documentation

Datasheet

L9638D013TR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

L9638D013TR Specifications

Attribute	Attribute Value

Part Number	L9638D013TR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW150769200
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	26.0V (max)
Number of Circuits	1 Circuit
Data Rate	20.0 kbps
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	6V ~ 26V
	expand all
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Unknown
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

DESCRIPTION
The L9638 is a monolithic integrated circuit for LIN-bus interface function between the protocol handler in the controller and the physical bus in automotive applications. As well as it can be used in standard ISO 9141 systems.
FEATURES
■ Single-wire transceiver for LIN-protocol
■ Transmission rate up to 20 kbaud
■ Operating power supply voltage range 6V ≤ Vs ≤ 26V (40V for transients)
■ Low quiescent current in sleep mode (typ.10µA)
■ Wake-up through LIN-bus, Enable input (from µC CMOS compatible) or Wake-up input (edge driven)
■ Wide input and output range -24V ≤ VLIN ≤ Vs
■ Integrated pull/down/up resistors for LIN, TxD, RxD, EN, INH
■ Inhibit output with low resistance (<40Ω) versus Vs and short circuit protection
■ CMOS compatible TxD, RxD Interface
■ EMI robustness optimised
■ Thermal shutdown and LIN short circuit protection
