LF347N - TI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoLF347N
-
ManufacturerTI
-
ChipWorker Part#CW36646
-
CategoryOperational Amplifier, OP Amp IC
-
PackageDIP-14
-
DescriptionOperational Amplifier, Quad, 4 Amplifier, 3MHz, 13V/µs, ± 3.5V to ± 18V, DIP, 14Pins
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
LF347N Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
LF347N Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | LF347N |
| Manufacturer | TI |
| ChipWorker Part# | CW36646 |
| Category | Operational Amplifier, OP Amp IC |
| Documentation | Datasheet |
| Mounting Style | Through Hole |
| Number of Pins | 14 Pin |
| Case/Package | DIP-14 |
| Supply Voltage (DC) | 18.0 V |
| Operating Voltage | 3.5V ~ 18V |
| Output Current | 31.0 mA |
| Supply Current | 8 mA |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 14 Position |
| Power Dissipation | 0.68 W |
| Common Mode Rejection Ratio | 70 dB |
| Input Offset Drift | 10.0 µV/K |
| Bandwidth | 3 MHz |
| Slew Rate | 13.0 V/μs |
| Gain Bandwidth Product | 3 MHz |
| Input Offset Voltage | 5 mV |
| Input Bias Current | 50 pA |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Gain Bandwidth | 3 MHz |
| Power Dissipation (Max) | 680 mW |
| Minimum CMRR Range | 70 dB |
| Supply Voltage (Max) | 18 V |
| expand all | |
| Size-Length | 19.3 mm |
| Size-Width | 6.35 mm |
| Size-Height | 4.57 mm |
| Operating Temperature | 0℃ ~ 70℃ |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2014/12/17 |
Product Description
- The LF347N is a high-speed quad general-purpose JFET-input Operational Amplifier requires low supply current yet maintains a large gain-bandwidth product and a fast slew rate. In addition, their matched high-voltage JFET inputs provide very low input bias and offset current. The LF347 can be used in applications such as high-speed integrators, digital-to-analogue converters, sample-and-hold circuits and many other circuits.
- 50pA Typical low input bias current
- 0.01pA Typical low input noise current
- Low total harmonic distortion
