LMV321M7 - TI
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoLMV321M7
-
ManufacturerTI
-
ChipWorker Part#CW74968066
-
CategoryAmplifier, Buffer IC
-
PackageSC-70-5
-
DescriptionGeneral Purpose, Low Voltage, ail-to- ail Output Operational Amplifiers 5-SC70 -40℃ to 85℃
-
DocumentationDatasheet
Payment Methods and Delivery
{{ estimate }}
LMV321M7 Global Supplier
| {{ supplierTable.supplier }} | {{ supplierTable.part }} | {{ supplierTable.availability }} | MOQ | {{ supplierTable.delivery_date }} | {{ supplierTable.buy }} | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
{{ skuList.vendorName }}
|
{{ noList.partNo }}
{{ strFormat(skuList.part_no) }}
{{ skuList.part_no }}
{{ skuList.mfrEn }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
{{ skuList.moq }} - |
{{ceilNumber(skuList.minDeliveryDay,skuList.maxDeliveryDay)}} {{delivery_date}}
6 {{delivery_date}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
|
{{ skuList.vendorName }}
|
{{ skuList.part_no }}
{{ skuList.mfrEn }}
{{ noList.partNo }}
{{ noList.mfr }}
|
{{ numFormat(skuList.stockQty) }}
{{ search_item }}
|
- |
{{outStock}}
|
{{ formatQuantity(priceList.quantity) }}
{{ ToEffectiveNum(priceList.price) }}
{{viewMore}}
|
- | ${{UpToFourDecimals(priceCalc,skuList.rate)}} |
|
|
{{viewMore}}
|
|||||||||||||||
|
{{viewMore}}
|
|||||||||||||||
|
DigiKey
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,1)}} |
|
||||||||
|
Arrow
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.96)}} |
|
||||||||
|
Mouser
|
{{noList.partNo}}
{{noList.mfr}}
|
0
{{ search_item }}
|
- | {{outStock}} | - | ${{UpToFourDecimals(priceCalc,0.92)}} |
|
||||||||
|
{{submitRFQ}}
|
|||||||||||||||
{{ apiText }}{{ apiTime }}(UTC+8)
LMV321M7 Specifications
| Attribute | Attribute Value |
|---|---|
| Part Number | LMV321M7 |
| Manufacturer | TI |
| ChipWorker Part# | CW74968066 |
| Category | Amplifier, Buffer IC |
| Documentation | Datasheet |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | SC-70-5 |
| Output Current | 60.0 mA |
| Supply Current | 130 µA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Input Offset Drift | 5.00 µV/K |
| Slew Rate | 1.00 V/μs |
| Gain Bandwidth Product | 1 MHz |
| Input Offset Voltage | 1.7 mV |
| Input Bias Current | 15 nA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Gain Bandwidth | 1 MHz |
| Minimum CMRR Range | 50 dB |
| expand all | |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
Product Description
- DESCRIPTION
- The LMV358-N/LMV324-N are low voltage (2.7V to 5.5V) versions of the dual and quad commodity op amps LM358/LM324 (5V to 30V). The LMV321-N is the single channel version. The LMV321-N/LMV358-N/LMV324-N are the most cost effective solutions for applications where low voltage operation, space efficiency, and low price are important. They offer specifications that meet or exceed the familiar LM358/LM324. The LMV321-N/LMV358-N/LMV324-N have rail-to-rail output swing capability and the input common-mode voltage range includes ground. They all exhibit excellent speed to power ratio, achieving 1 MHz of bandwidth and 1 V/µs slew rate with low supply current.
- FEATURES
- • (For V+ = 5V and V− = 0V, unless otherwise specified)
- • LMV321-N, LMV358-N, and LMV324-N are
- available in Automotive AEC-Q100 Grade 1 & 3
- versions
- • Guaranteed 2.7V and 5V performance
- • No crossover distortion
- • Industrial temperature range −40°C to +125°C
- • Gain-bandwidth product 1 MHz
- • Low supply current
- • LMV321-N 130 μA
- • LMV358-N 210 μA
- • LMV324-N 410 μA
- • Rail-to-rail output swing @ 10 kΩ V+ − 10 mV & V− \+ 65 mV
- • VCM Range −0.2V to V+ − 0.8V
- APPLICATIONS
- • Active filters
- • General purpose low voltage applications
- • General purpose portable devices
