LPV324 - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

36 points

Part No

LPV324
Manufacturer

TI
ChipWorker Part#

CW322795619
Package

TSSOP-14
Description

the lpv321/358/324 devices are low-power (9A per channel at 5V) versions of the lmv321/358/324 operational amplifie...
Documentation

Datasheet
Ships from

Moscow
Наличие

530 pcs In Stock
Estimated Price

Price on Request

Buy LPV324

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LPV324 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LPV324 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LPV324
Manufacturer	TI
ChipWorker Part#	CW322795619
Documentation	Datasheet
Case/Package	TSSOP-14
	expand all
Product Lifecycle Status
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

The LPV321/358/324 devices are low-power (9 µA per channel at 5 V) versions of the LMV321/358/324 operational amplifiers. These are additions to the LMV321/358/324 family of commodity operational amplifiers.
The LPV321/358/324 devices are the most cost-effective solutions for applications where low voltage, low-power operation, space saving, and low price are needed. These devices have rail-to-rail output-swing capability, and the input common-mode voltage range includes ground. They all exhibit excellent speed-power ratios, achieving 152 kHz of bandwidth, with a supply current of only 9 µA typical.
The LPV321, LPV358, and LPV324 are characterized for operation from 40°C to 85°C. The LPV321I, LPV358I, and LPV324I are characterized for operation from 40°C to 125°C.
2.7-V and 5-V Performance
40°C to 125°C Specification at 5 V
No Crossover Distortion
Gain Bandwith of 152 kHz
Low Supply Current
LPV321 . . . 9 µA
LPV358 . . . 15 µA
LPV324 . . . 28 µA
Rail-to-Rail Output Swing at 100-k Load
VCC+ 3.5 mV
VCC \+ 90 mV
VICR . . . 0.2 V to VCC+ 0.8 V
Stable With Capacitive Load of 1000 pF
Applications
Active Filters
General-Purpose, Low-Voltage Applications
Low-Power and/or Portable Applications
Latch-Up Performance Exceeds 100 mA per JESD 78, Class II
ESD Protection Exceeds JESD 22
2000-V Human-Body Model (A114-A)
200-V Machine Model (A115-A)
1000-V Charged-Device Model (C101)
