MAX3223EUP+ ,Interface IC, Interface Controller - Maxim Integrated

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

115 points

Part No

MAX3223EUP+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW48951127
Category

Interface IC, Interface Controller
Package

TSSOP-20
Description

Dual Transmitter/Receiver RS-232 20Pin TSSOP
Documentation

Datasheet
Ships from

Moscow
Наличие

531 pcs In Stock
Estimated Price

$ 4.28

Buy MAX3223EUP+

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MAX3223EUP+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MAX3223EUP+ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MAX3223EUP+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW48951127
Category	Interface IC, Interface Controller
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	TSSOP-20
Supply Voltage (DC)	3.00V (min)
Number of Positions	20 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	6.6 mm
Size-Width	4.5 mm
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

Product Description

The MAX3223EUP+ is a 3V to 5.5V RS232 transceiver with AutoShutdown in 20 pin TSSOP package. Whenever the device does not sense a valid signal level on the receiver inputs, the onboard power supply and driver turns to shut down. This occurs if the RS232 cable is disconnected or if the transmitters of the connected peripheral are turned off. The system turns on again when a valid level is applied to any RS232 receiver input. It requires only 0.1µF capacitors in 3.3V operation. The high efficiency, dual charge pump power supply and a low dropout transmitter combine to deliver true RS232 performance from a single +3V to +5.5V supply.
Two drivers and two receivers
Operating temperature range from -40°C to 85°C
AutoShutdown feature enabled after no activity on receiver input for 30µs
Supply current is 1µA in shutdown mode
Software control option for shutdown
Integrated charge pump circuitry eliminates need of ±12 supply & operates in single 3.3V/5V supply

expand all
