MAX6675ISA+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW13757000
Category

Instrumentation Amplifier IC
Package

SOIC-8
Description

Sensor and Detector Interface 5.5V SPI 8Pin SOIC N
Documentation

Datasheet

MAX6675ISA+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MAX6675ISA+ Specifications

Attribute	Attribute Value

Part Number	MAX6675ISA+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW13757000
Category	Instrumentation Amplifier IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	3.00V (min)
Output Voltage	2.6 V
Supply Current	1.5 mA
Number of Positions	8 Position
Number of Bits	12 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Supply Voltage	3.5.5 VDC
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-20℃ ~ 85℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Each
RoHS	Non-Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Product Description

The MAX6675 performs cold-junction compensation and digitizes the signal from a type-K thermocouple. The data is output in a 12-bit resolution, SPI compatible, read-only format. This converter resolves temperatures to 0.25°C, allows readings as high as +1024°C, and exhibits thermocouple accuracy of 8LSBs for temperatures ranging from 0°C to +700°C.
Direct digital conversion of Type -K thermocouple output
Cold-junction compensation
Simple SPI-compatible serial interface
Open thermocouple detection
