MBR20200CT ,Schottky Diode - Taiwan Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

82 points

Part No

MBR20200CT
Manufacturer

Taiwan Semiconductor
ChipWorker Part#

CW77346458
Category

Schottky Diode
Package

TO-220
Description

TAIWAN SEMICONDUCTOR MBR20200CT Schottky Rectifier, 200V, 20A, Dual Common Cathode, TO-220AB, 3Pins, 1.23V
Documentation

Datasheet
Ships from

Moscow
Наличие

5635 pcs In Stock
Estimated Price

$ 0.7

Buy MBR20200CT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MBR20200CT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MBR20200CT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MBR20200CT
Manufacturer	Taiwan Semiconductor
ChipWorker Part#	CW77346458
Category	Schottky Diode
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220
Load Current	20 A
Number of Positions	3 Position
Forward Current	20 A
Max Forward Surge Current (Ifsm)	150 A
Maximum Forward Voltage (Max)	1.23 V
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature (Max)	150 ℃
	expand all
Operating Temperature	-65℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The MBR20200CT is a Rectifier Diode with moulded plastic body, metal silicon junction, majority carrier conduction and lead-free terminals. The rectifier diode features solderable terminals as per MIL-STD-750, method 2026 standard, low power loss and high efficiency. Polarity marked on the body.
High current capability
Low forward voltage drop
High surge capability
140V Maximum RMS voltage
200V Maximum DC blocking voltage
320pF Typical junction capacitance

expand all
