MC1455P1G - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MC1455P1G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW98532703
Category

Timer IC
Package

PDIP-8
Description

Standard Timer Single 0°C 70℃ Automotive 8Pin PDIP Tube
Documentation

Datasheet

MC1455P1G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MC1455P1G Specifications

Attribute	Attribute Value

Part Number	MC1455P1G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW98532703
Category	Timer IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	PDIP-8
Supply Voltage (DC)	16.0 V
Operating Voltage	4.5V ~ 16V
Current Rating	10.0 A
Supply Current	10 mA
Number of Circuits	1 Circuit
Number of Positions	8 Position
Power Dissipation	0.625 W
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	625 mW
Supply Voltage	4.5V ~ 16V
Supply Voltage (Max)	16 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	10.16 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

Timers
The MC1455 monolithic timing circuit is a highly stable controller capable of producing accurate time delays or oscillation. Additional terminals are provided for triggering or resetting if desired. In the time delay mode, time is precisely controlled by one external resistor and capacitor. For astable operation as an oscillator, the free−running frequency and the duty cycle are both accurately controlled with two external resistors and one capacitor. The circuit may be triggered and reset on falling waveforms, and the output structure can source or sink up to 200 mA or drive TTL circuits.
Features
•Direct Replacement for NE555 Timers
•Timing from Microseconds through Hours
•Operates in Both Astable and Monostable Modes
•Adjustable Duty Cycle
•High Current Output Can Source or Sink 200 mA
•Output Can Drive TTL
•Temperature Stability of 0.005% per °C
•Normally ON or Normally OFF Output
•Pb−Free Packages are Available

expand all
