MGJ2D121505SC ,DC to DC Converter, DC/DC Converter - muRata
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
101 points
-
Part NoMGJ2D121505SC
-
ManufacturermuRata
-
ChipWorker Part#CW29001267
-
CategoryDC to DC Converter, DC/DC Converter
-
PackageSIP-7
-
DescriptionModule DC-DC 12Vin 2Out 15V/-5V 0.08A/0.04A 2W 5Pin SIP Module
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие132 pcs In Stock
-
Estimated Price$ 9.73
