MID400 - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MID400
Manufacturer

Fairchild
ChipWorker Part#

CW15223603
Category

Optocoupler, Optoisolator
Package

DIP-8
Description

Optocoupler Logic Output Open Collector AC Input 1Channel 8Pin Plastic Dip Black Bulk
Documentation

Datasheet

MID400 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MID400 Specifications

Attribute	Attribute Value

Part Number	MID400
Manufacturer	Fairchild
ChipWorker Part#	CW15223603
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Voltage Rating (DC)	7.00 V
Input Voltage (DC)	1.50V (max)
Output Voltage	7.00 V
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Forward Voltage	1.5V (Max)
Input Current	30.0 mA
Power Dissipation	115 mW
Rise Time	1.00 ms
Isolation Voltage	2500 Vrms
Forward Current	30 mA
Maximum Forward Voltage (Max)	1.5 V
Forward Current (Max)	30 mA
Fall Time	1 ms
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	115 mW
Supply Voltage	7 V
	expand all
Size-Length	9.91 mm
Size-Width	6.86 mm
Size-Height	3.94 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The MID400 is an Optically Isolated AC Line-to-Logic Optocoupler. The AC line voltage is monitored by two back-to-back GaAs LED diodes in series with an external resistor. A high gain detector circuit senses the LED current and drives the output gate to a logic low condition. It has been designed solely for the use as an AC line monitor. It is recommended for use in any AC-to-DC control application where excellent optical isolation, solid state reliability, TTL compatibility, small size, low power and low frequency operations are required.
