MMSZ4697T1G ,Zener Diode, Zener - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

135 points

Part No

MMSZ4697T1G
Manufacturer

ON Semiconductor
ChipWorker Part#

CW2893167
Category

Zener Diode, Zener
Package

SOD-123
Description

SOD-123 10V 0.5W(1/2W)
Documentation

Datasheet
Ships from

Moscow
Наличие

47744 pcs In Stock
Estimated Price

$ 0.02

Buy MMSZ4697T1G

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

MMSZ4697T1G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

MMSZ4697T1G Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	MMSZ4697T1G
Manufacturer	ON Semiconductor
ChipWorker Part#	CW2893167
Category	Zener Diode, Zener
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SOD-123
Voltage Rating (DC)	10.0 V
Capacitance Tolerance	±5 %
Power Rating	500 mW
Breakdown Voltage	10.5 V
Number of Positions	2 Position
Forward Voltage	900mV @10mA
Power Dissipation	500 mW
Test Current	0.05 mA
Zener Voltage	10 V
Input Power (Max)	500 mW
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	500 mW
	expand all
Size-Length	2.84 mm
Size-Width	1.8 mm
Size-Height	1.25 mm
Material	Plastic
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The MMSZ4xxxT1G series surface mount Voltage Regulator Zener Diode designed for optimal automated board assembly. This device provides a convenient alternative to the leadless 34-package style. It comes with void free transfer-moulded thermosetting plastic case.
500mW Rating on FR-4 or FR-5 board
1.8 to 43V Wide Zener reverse voltage rating
Small package size for high density applications
ESD rating of Class 3 (>16kV) per human body model
AEC-Q101 qualified and PPAP capable
