MMZ2012Y202BTD25 - TDK

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MMZ2012Y202BTD25
Manufacturer

TDK
ChipWorker Part#

CW15204510
Category

Ferrite
Package

0805
Description

Ferrite Beads Multi-Layer 2KΩ 25% 100MHz 400mA 500mOhm DCR 0805 Automotive
Documentation

Datasheet

MMZ2012Y202BTD25 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MMZ2012Y202BTD25 Specifications

Attribute	Attribute Value

Part Number	MMZ2012Y202BTD25
Manufacturer	TDK
ChipWorker Part#	CW15204510
Category	Ferrite
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	0805
Test Frequency	100 MHz
DC Resistance (DCR)	0.5 Ω
Current Rating (Max)	400 mA
Resistance (DC Max)	500 mΩ
	expand all
Size-Length	2 mm
Size-Width	1.25 mm
Size-Height	1.05 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
Minimum Packing Quantity	4000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

2 kOhms @ 100MHz 1 Signal Line Ferrite Bead 0805 (2012 Metric) 400mA 500mOhm
