MT88L70AS - Mitel

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MT88L70AS
Manufacturer

Mitel
ChipWorker Part#

CW382592929
RoHS

Lead free / RoHS Compliant
Description

3V Integrated DTMF Receiver
Documentation

Datasheet

MT88L70AS Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MT88L70AS Specifications

Attribute	Attribute Value

Part Number	MT88L70AS
Manufacturer	Mitel
ChipWorker Part#	CW382592929
Documentation	Datasheet
	expand all
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Description
The MT88L70 is a complete 3 Volt, DTMF receiver integrating both the bandsplit filter and digital decoder functions. The filter section uses switched capacitor techniques for high and low group filters; the decoder uses digital counting techniques to detect and decode all 16 DTMF tone pairs into a 4-bit code. External component count is minimized by on chip provision of a differential input amplifier, clock oscillator and latched three-state bus interface.
Features
• 2.7 - 3.6 volt operation
• Complete DTMF receiver
• Low power consumption
• Internal gain setting amplifier
• Adjustable guard time
• Central office quality
• Power-down mode
• Inhibit mode
• Functionally compatible with Mitel’s MT8870D
Applications
• Paging systems
• Repeater systems/mobile radio
• Credit card systems
• Remote control
• Personal computers
• Telephone answering machine
