PC354NJ0000F ,Optocoupler, Optoisolator - Sharp
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
146 points
-
Part NoPC354NJ0000F
-
ManufacturerSharp
-
ChipWorker Part#CW9465746
-
CategoryOptocoupler, Optoisolator
-
Package4-Mini-Flat
-
DescriptionAC Input-Transistor Output Optocoupler, 1Element, 3750V Isolation, ROHS COMPLIANT, PLASTIC, MINIFLAT-4
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие24 pcs In Stock
-
Estimated Price$ 0.16
