PHR-2 ,Connector Enclosure - JST

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

176 points

Part No

PHR-2
Manufacturer

JST
ChipWorker Part#

CW477061
Category

Connector Enclosure
Package

DIP
Description

JST (JAPAN SOLDERLESS TERMINALS) PHR-2 Wire-To-Board Connector, 2mm, 2Contacts, PH Series, 1Rows
Documentation

Datasheet
Ships from

Moscow
Наличие

148496 pcs In Stock
Estimated Price

$ 0.01

Buy PHR-2

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

PHR-2 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

PHR-2 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	PHR-2
Manufacturer	JST
ChipWorker Part#	CW477061
Category	Connector Enclosure
Documentation	Datasheet
Number of Pins	2 Pin
Case/Package	DIP
Pin Pitch	2.00 mm
Number of Contacts	2 Contact
Contact Plating	Tin
Current Rating	2 A
Insulation Resistance	1000 MΩ
Number of Rows	1 Row
Flammability Rating	UL 94 V-0
Number of Positions	2 Position
Current Rating (Max)	2 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
Voltage Rating	100 V
Maximum Contact Resistance (Max)	10 mΩ
	expand all
Size-Length	5.8 mm
Size-Width	4.5 mm
Size-Height	6.85 mm
Housing Color	White
Color	Natural
Contact Material	Phosphor Bronze
Material	Nylon
Housing Material	Nylon
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
HTS Code	8536698000
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

B2B-PH-SM4-TB(LF)(SN)

Product Description

The PH series housing from JST are 2.0mm pitch, single row housing for use with PH series crimp contacts.
Number of contacts varies from 2 to 16 pins
Polyamide 66, UL94V-0 material
Natural colour
