REF195GS - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

REF195GS
Manufacturer

ADI
ChipWorker Part#

CW93917959
Category

Voltage Reference
Package

SOIC-8
Description

V-Ref Precision 5V 30mA 8Pin SOIC N Tube
Documentation

Datasheet

REF195GS Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

REF195GS Specifications

Attribute	Attribute Value

Part Number	REF195GS
Manufacturer	ADI
ChipWorker Part#	CW93917959
Category	Voltage Reference
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Current Rating	45.0 A
Capacitance Tolerance	±0.2 %
Input Voltage (DC)	15.0V (max)
Output Voltage	5 V
Output Current	30 mA
Supply Current	45 μA
Number of Channels	1 Channel
Output Voltage (Min)	5 V
Input Voltage	5.1V ~ 15V
	expand all
Operating Temperature	-40℃ ~ 85℃ (TA)
Temperature Coefficient	±25 ppm/℃
Product Lifecycle Status	Obsolete
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Product Description

GENERAL DESCRIPTION
The REF19x series precision band gap voltage references use a patented temperature drift curvature correction circuit and laser trimming of highly stable, thin-film resistors to achieve a very low temperature coefficient and high initial accuracy.
FEATURES
Initial accuracy: ±2 mV maximum
Temperature coefficient: 5 ppm/°C maximum
Low supply current: 45 μA maximum
Sleep mode: 15 μA maximum
Low dropout voltage
Load regulation: 4 ppm/mA
Line regulation: 4 ppm/V
High output current: 30 mA
Short-circuit protection
