IRF640NPBF ,MOSFET, MOSFET Transistor - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

248 points

Part No

IRF640NPBF
Manufacturer

Infineon
ChipWorker Part#

CW69858
Category

MOSFET, MOSFET Transistor
Package

TO-220-3
Description

TO-220AB N-CH 200V 18A
Documentation

Datasheet
Ships from

Moscow
Наличие

1016 pcs In Stock
Estimated Price

$ 0.13

Buy IRF640NPBF

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

IRF640NPBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

IRF640NPBF Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	IRF640NPBF
Manufacturer	Infineon
ChipWorker Part#	CW69858
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Power Rating	150 W
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.15 Ω
Polarity	N-CH
Power Dissipation	150 W
Threshold Voltage	4 V
Input Capacitance	1160 pF
Drain to Source Voltage (Vds)	200 V
Breakdown Voltage (Drain to Source)	200 V
Continuous Drain Current (Ids)	18A
Rise Time	19 ns
Thermal Resistance	1℃/W (RθJC)
Input Capacitance (Ciss)	1160pF @25V(Vds)
Input Power (Max)	150 W
Fall Time	5.5 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	150W (Tc)
	expand all
Size-Length	10.67 mm
Size-Width	4.4 mm
Size-Height	8.77 mm
Material	Silicon
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The IRF640NPBF from International Rectifier is 200V single N channel HEXFET power MOSFET in TO-220AB package. This MOSFET features extremely low on resistance per silicon area, dynamic dv/dt rating, rugged, fast switching and fully avalanche rated as a result, power MOSFET are well know to provide extremely efficiency and reliability which can be used in wide variety of applications.
Drain to source voltage Vds is 200V
Gate to source voltage is ±20V
On resistance Rds(on) of 150mohm
Power dissipation Pd of 150W at 25°C
Continuous drain current Id of 18A at Vgs 10V and 25°C
Operating junction temperature range from -55°C to 175°C
