SA12AG Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | SA12AG | |
| Manufacturer | ON Semiconductor | |
| ChipWorker Part# | CW40208627 | |
| Category | TVS Diode | |
| Documentation | Datasheet | |
| Mounting Style | Through Hole | |
| Number of Pins | 2 Pin | |
| Case/Package | DO-204AC | |
| Voltage Rating (DC) | 12.0 V | |
| Operating Voltage | 12 V | |
| Power Rating | 500 W | |
| Breakdown Voltage | 13.3 V | |
| Number of Circuits | 1 Circuit | |
| Number of Positions | 2 Position | |
| Power Dissipation | 500 W | |
| Clamping Voltage | 19.9 V | |
| Max Repetitive Reverse Voltage (Vrrm) | 12V | |
| Test Current | 1 mA | |
| Max Breakdown Voltage | 14.7 V | |
| Peak Pulse Power | 500 W | |
| Min Breakdown Voltage | 13.3 V | |
| Reverse Breakdown Voltage | 13.3 V | |
| Operating Temperature (Max) | 150 ℃ | |
| Operating Temperature (Min) | -55 ℃ | |
| Junction Temperature | -55℃ ~ 150℃ | |
| expand all | ||
| Size-Length | 7.6 mm | |
| Size-Diameter | 3.60 mm | |
| Operating Temperature | -55℃ ~ 150℃ | |
| Product Lifecycle Status | Active | |
| Packaging | Bulk | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free | |
| REACH SVHC Compliance Edition | 2015/12/17 | |
| ECCN Code | EAR99 |
Similar & Replacement Parts
Similar products
Product Description
- 19.9V Clamp 25.1A Ipp Tvs Diode Through Hole Axial
