SG2525AN ,Voltage Regulator - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

101 points

Part No

SG2525AN
Manufacturer

ST Microelectronics
ChipWorker Part#

CW5099200
Category

Voltage Regulator
Package

DIP-16
Description

Voltage Mode PWM Controller 500mA 400kHz 16Pin PDIP Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.99

Buy SG2525AN

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SG2525AN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SG2525AN Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SG2525AN
Manufacturer	ST Microelectronics
ChipWorker Part#	CW5099200
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Frequency	500 kHz
Supply Voltage (DC)	8.00V (min)
Number of Outputs	2 Output
Output Voltage	0.2.5.6 V
Output Current	500 mA
Number of Channels	2 Channel
Number of Positions	16 Position
Power Dissipation	1000 mW
Quiescent Current	14.0 mA
Rise Time	100 ns
Switching Frequency	100Hz ~ 400kHz
Duty Cycle	49 %
Maximum Duty Cycle	49 %
Fall Time	50 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-25 ℃
Power Dissipation (Max)	1000 mW
Supply Voltage	8.35 V
Supply Voltage (Max)	35 V
Supply Voltage (Min)	8 V
Input Voltage	8V ~ 35V
	expand all
Size-Length	20 mm
Size-Width	7.1 mm
Size-Height	5.1 mm
Operating Temperature	-25℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The SG2525AN is a Pulse Width Modulator (PWM) designed to offer improved performance and lowered external parts count when used in designing all types of switching power supplies. The on-chip 5.1V reference is trimmed to ±1% and the input common-mode range of the error amplifier includes the reference voltage eliminating external resistors. A sync input to the oscillator allows multiple units to be slaved or a single unit to be synchronized to an external system clock. A single resistor between the CT and the discharge terminals provide a wide range of dead time adjustment. These devices also feature built-in soft-start circuitry with only an external timing capacitor required. A shutdown terminal controls both the soft-start circuitry and the output stages, providing instantaneous turn off through the PWM latch with pulsed shutdown, as well as soft-start recycle with longer shutdown commands.
Separate oscillator sync terminal
Adjustable deadtime control
Internal soft-start
Pulse-by-pulse shutdown
Input undervoltage lockout with hysteresis
Latching PWM to prevent multiple pulses
Dual source/sink output drivers
