SKYPER 32 R ,FET Driver - Semikron

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

94 points

Part No

SKYPER 32 R
Manufacturer

Semikron
ChipWorker Part#

CW14255914
Category

FET Driver
Package

PCB
Description

SEMIKRON SKYPER 32R IC, DUAL IGBT DRIVER, PCB-40
Documentation

Datasheet
Ships from

Moscow
Наличие

25 pcs In Stock
Estimated Price

$ 544.57

Buy SKYPER 32 R

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SKYPER 32 R Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SKYPER 32 R Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SKYPER 32 R
Manufacturer	Semikron
ChipWorker Part#	CW14255914
Category	FET Driver
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	40 Pin
Case/Package	PCB
Supply Voltage (DC)	14.4V (min)
Number of Outputs	2 Output
Output Current	0.05 A
Number of Positions	40 Position
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	14.4.15.6 VDC
Supply Voltage (Max)	15.6 V
Supply Voltage (Min)	14.4 V
	expand all
Size-Length	57 mm
Size-Width	64 mm
Size-Height	19 mm
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The SKYPER 32 R is a Dual IGBT Driver IC, the 32-core constitutes an interface between IGBT modules and the controller. The driver is developed according to the requirements of UL standard. This core is a half bridge driver. Basic functions for driving, potential separation and protection are integrated in the driver. Thus it can be used to build up a driver solution for IGBT module.
Two output channels
Integrated potential free power supply for secondary side
Short pulse suppression
Under voltage protection
Drive interlock (dead time) top/bottom (DT)
Shutdown input
Up to 1200VDC bus voltage

expand all
