SN65220DBVT ,TVS Diode - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

162 points

Part No

SN65220DBVT
Manufacturer

TI
ChipWorker Part#

CW6405792
Category

TVS Diode
Package

SOT-23-6
Description

TEXAS INSTRUMENTS SN65220DBVT ESD Protection Device, TVS, SOT-23, 6Pins, 6V, 385mW
Documentation

Datasheet
Ships from

Moscow
Наличие

445 pcs In Stock
Estimated Price

$ 0.26

Buy SN65220DBVT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

SN65220DBVT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

SN65220DBVT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	SN65220DBVT
Manufacturer	TI
ChipWorker Part#	CW6405792
Category	TVS Diode
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	SOT-23-6
Operating Voltage	6 V
Current Rating	1.00 A
Capacitance	35 pF
Power Rating	60 W
Breakdown Voltage	7 V
Number of Circuits	1 Circuit
Number of Channels	2 Channel
Number of Positions	6 Position
Power Dissipation	385 mW
Clamping Voltage	7 V
Max Breakdown Voltage	8 V
Peak Pulse Power	60 W
Min Breakdown Voltage	6.5 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	385 mW
	expand all
Size-Length	2.9 mm
Size-Width	1.6 mm
Size-Height	1.15 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The SN65220DBVT is a single universal serial bus port Transient Suppressor. This device provides electrical noise transient protection to Universal Serial Bus (USB) low and full-speed ports. The input capacitance of 35 pF makes it unsuitable for high-speed USB 2.0 applications. Any cabled I/O can be subjected to electrical noise transients from various sources. These noise transients can cause damage to the USB transceiver and/or the USB ASIC if they are of sufficient magnitude and duration. The ESD performance of the SN65220 device is measured at the system level, according to IEC61000-4-2. However, system design impacts the results of these tests. To accomplish a high compliance level requires careful board design and layout techniques.
1µA at 6V Maximum low leakage current
35pF (typical) Low capacitance
-40 to 85°C Operating temperature range
ESD sensitive device, take proper precaution while handling the device.
