STF23NM60ND ,High Voltage MOS Transistor - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

46 points

Part No

STF23NM60ND
Manufacturer

ST Microelectronics
ChipWorker Part#

CW59960269
Category

High Voltage MOS Transistor
Package

TO-220-3
Description

TO-220FP N-CH 600V 19.5A
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 3.35

Buy STF23NM60ND

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

STF23NM60ND Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

STF23NM60ND Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	STF23NM60ND
Manufacturer	ST Microelectronics
ChipWorker Part#	CW59960269
Category	High Voltage MOS Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.15 Ω
Polarity	N-Channel
Power Dissipation	35 W
Threshold Voltage	4 V
Drain to Source Voltage (Vds)	600 V
Continuous Drain Current (Ids)	19.5A
Rise Time	19 ns
Input Capacitance (Ciss)	2050pF @50V(Vds)
Input Power (Max)	35 W
Fall Time	42 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	35W (Tc)
	expand all
Size-Width	4.6 mm
Operating Temperature	150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The STF23NM60ND is a FDmesh™ II N-channel Power MOSFET features low input capacitance and gate charge. This FDmesh™ II Power MOSFET with intrinsic fast-recovery body diode is produced using the second generation of MDmesh™ technology. Utilizing a new strip-layout vertical structure, this revolutionary device features extremely low ON-resistance and superior switching performance. It is ideal for bridge topologies and ZVS phase-shift converters.
The worldwide best RDS (ON) area amongst the fast recovery diode device
100% Avalanche tested
Low gate input resistance
High dV/dt and avalanche capabilities
