STP55NF06L - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

STP55NF06L
Manufacturer

ST Microelectronics
ChipWorker Part#

CW3376793
Category

MOSFET, MOSFET Transistor
Package

TO-220-3
Description

TO-220 N-CH 60V 55A
Documentation

Datasheet

STP55NF06L Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

STP55NF06L Specifications

Attribute	Attribute Value

Part Number	STP55NF06L
Manufacturer	ST Microelectronics
ChipWorker Part#	CW3376793
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Voltage Rating (DC)	60.0 V
Current Rating	55.0 A
Number of Channels	1 Channel
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.014 Ω
Polarity	N-Channel
Power Dissipation	95 W
Threshold Voltage	1.7 V
Drain to Source Voltage (Vds)	60 V
Breakdown Voltage (Drain to Source)	60.0 V
Breakdown Voltage (Gate to Source)	±16.0 V
Continuous Drain Current (Ids)	55.0 A
Rise Time	100 ns
Input Capacitance (Ciss)	1700pF @25V(Vds)
Input Power (Max)	95 W
Fall Time	20 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	95W (Tc)
	expand all
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	9.15 mm
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The STP55NF06L is a N-channel Power MOSFET, latest development of STMicroelectronis unique Single Feature Size™ strip-based process. The resulting transistor shows extremely high packing density for low on-resistance, rugged avalanche characteristics and less critical alignment steps therefore a remarkable manufacturing reproducibility.
Exceptional dv/dt Capability
100% Avalanche Tested
Application Oriented Characterization
