STTH2003CFP Specifications
Consulting Engineer >>| Attribute | Attribute Value | |
|---|---|---|
| Part Number | STTH2003CFP | |
| Manufacturer | ST Microelectronics | |
| ChipWorker Part# | CW16222010 | |
| Category | Diode Array, TVS Diode Array | |
| Documentation | Datasheet | |
| Mounting Style | Through Hole | |
| Number of Pins | 3 Pin | |
| Case/Package | TO-220-3 | |
| Voltage Rating (DC) | 300 V | |
| Current Rating | 10.0 A | |
| Forward Voltage | 1.25V @10A | |
| Thermal Resistance | 4.6 ℃/W | |
| Reverse recovery time | 35 ns | |
| Forward Current | 20 A | |
| Maximum Forward Voltage (Max) | 1.25V @10A | |
| Forward Current (Max) | 20000 mA | |
| Operating Temperature (Max) | 175 ℃ | |
| Operating Temperature (Min) | -65 ℃ | |
| Junction Temperature | 175℃ (Max) | |
| expand all | ||
| Size-Length | 10.4 mm | |
| Size-Width | 4.6 mm | |
| Size-Height | 9.3 mm | |
| Operating Temperature | -65℃ ~ 175℃ | |
| Product Lifecycle Status | Active | |
| Packaging | Tube | |
| RoHS | RoHS Compliant | |
| Lead-Free Status | Lead Free |
Similar & Replacement Parts
Similar products
Product Description
- Description
- Dual center tap Fast Recovery Epitaxial Diodes suited for Switch Mode Power Supply and high frequency DC/DC converters. Packaged in TO-220AB, TO-220FPAB, I2PAK or D2PAK, this device is especially intended for secondary rectification.
- Features and benefits
- ■ Combines highest recovery and reverse voltage performance
- ■ Ultra-fast, soft and noise-free recovery
- ■ Insulated packages: TO-220FPAB
- Electric insulation: 2000 V DC
- Capacitance: 12 pF
