TDGL021 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TDGL021
Manufacturer

Microchip
ChipWorker Part#

CW74485766
Category

Microprocessor Development Kit
Description

PIC32MX695F512L Microcontroller Development Board 80MHz CPU 32KB RAM 512KB Flash
Documentation

Datasheet

TDGL021 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TDGL021 Specifications

Attribute	Attribute Value

Part Number	TDGL021
Manufacturer	Microchip
ChipWorker Part#	CW74485766
Category	Microprocessor Development Kit
Documentation	Datasheet
Frequency	2.4 GHz
RAM Memory Size	32 KB
Number of Bits	32 Bit
Core Architecture	PIC
Core Sub-Architecture	PIC32
	expand all
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	5A992.c

Product Description

The TDGL021 is a chipKIT™ WF32™ WiFi Development Board an easy-to-use platform for developing Wi-Fi® applications. As with other chipKIT boards, it uses a modified version of the original Arduino® IDE for compatibility with existing code examples, tutorials and resources. Also compatible with MPLAB® X IDE. The WF32 includes several peripherals on board, including Wi-Fi radio module, USB OTG (host or device) interface, microSD™ card slot, buttons, LEDs, potentiometer and lots of extra I/O. A full-featured HTML server application is available by download. Can be powered by USB or an external power supply.
PIC32MX695F512L processor with 512kB flash, 32kB RAM up to 80MHz operating speed
MRF24WG0MA Wi-Fi module
microSD card connector
USB 2.0 OTG interface
Four user LEDs, two buttons
42 Available I/O lines
