TDA5210 ,RF Receiver - Infineon

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

94 points

Part No

TDA5210
Manufacturer

Infineon
ChipWorker Part#

CW36423896
Category

RF Receiver
Package

TSSOP-28
Description

RF Receiver ASK/FSK 5V 28Pin TSSOP
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.11

Buy TDA5210

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TDA5210 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TDA5210 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TDA5210
Manufacturer	Infineon
ChipWorker Part#	CW36423896
Category	RF Receiver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	28 Pin
Case/Package	TSSOP-28
Frequency	810MHz ~ 870MHz, 400MHz ~ 440MHz
Number of Positions	28 Position
Data Rate	100 kbps
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	5 V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	9.7 mm
Size-Width	4.4 mm
Size-Height	1 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Description:
The IC is a very low power consumption single chip FSK/ASK Superheterodyne Receiver (SHR) for the frequency bands 810 to 870 MHz and< 400 to 440 MHz that is pin compatible with the ASK Receiver TDA5200. The IC offers a high level of integration and needs only a few external components. The device contains a low noise amplifier (LNA), a double balanced mixer, a fully integrated VCO, a PLL synthesiser, a crystal oscillator, a limiter with RSSI generator, a PLL FSK demodulator, a data filter, a data comparator (slicer) and a peak detector. Additionally there is a power down feature to save battery life.
Summary of Features:
Low supply current (typ. at 868MHz Is = 5.9mA in FSK mode,Is = 5.2mA in ASK mode)
Supply voltage range 5V ±10%
Power down mode with very low supply current (50nA typ)
FSK and ASK demodulation capability
Fully integrated VCO and PLL Synthesiser
ASK sensitivity < –107dBm
Selectable frequency ranges 810 - 870 MHz and 400-440 MHz
Limiter with RSSI generation,operating at 10.7MHz
Selectable reference frequency
2nd order low pass data filter withexternal capacitors
Data slicer with self-adjustingthreshold
FSK sensitivity <-100dBm

expand all
