TL082CDT - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

TL082CDT
Manufacturer

ST Microelectronics
ChipWorker Part#

CW311290
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

Operational Amplifier, Dual, 2 Amplifier, 4MHz, 16V/µs, 6V to 36V, SOIC, 8Pins
Documentation

Datasheet

TL082CDT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TL082CDT Specifications

Attribute	Attribute Value

Part Number	TL082CDT
Manufacturer	ST Microelectronics
ChipWorker Part#	CW311290
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Operating Voltage	7V ~ 36V
Output Current	40 mA
Supply Current	1.4 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Power Dissipation	680 mW
Common Mode Rejection Ratio	70 dB
Bandwidth	4 MHz
Slew Rate	16.0 V/μs
Gain Bandwidth Product	4 MHz
Input Offset Voltage	3 mV
Input Bias Current	20 pA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Gain Bandwidth	4 MHz
Power Dissipation (Max)	680 mW
Minimum CMRR Range	70 dB
Supply Voltage	6V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	6 V
	expand all
Size-Length	4.9 mm
Size-Width	4 mm
Size-Height	1.65 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99

Product Description

The TL082CDT is a general purpose dual JFET input Operational Amplifier incorporates well matched, high voltage JFET and bipolar transistors in a monolithic integrated circuit. The device features high slew rates, low offset voltage temperature coefficient, low input bias and offset current.
Wide common-mode (up to VCC+) and differential voltage ranges
Output short-circuit protection
High input impedance JFET input stage
Internal frequency compensation
Latch-up free operation
680mW Power dissipation
