Part No

TLE4917
Manufacturer

Infineon
ChipWorker Part#

CW41291428
Category

Magnetic Sensor
Package

TSOP-6-6
Description

Hall Effect Sensor 2mA Omnipolar 2.5V/3.3V/5V 6Pin TSOP T/R
Documentation

Datasheet

TLE4917 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

TLE4917 Specifications

Attribute	Attribute Value

Part Number	TLE4917
Manufacturer	Infineon
ChipWorker Part#	CW41291428
Category	Magnetic Sensor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOP-6-6
Supply Voltage (DC)	2.40V (min)
Output Current	2 mA
Supply Current	1.1 mA
Number of Positions	6 Position
Output Current (Max)	2 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.4V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.4 V
	expand all
Size-Length	2.9 mm
Size-Width	1.6 mm
Size-Height	1 mm
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The TLE4917 is an Integrated Hall-Effect Sensor designed specifically to meet the requirements of low-power devices. Precise magnetic switching points and high temperature stability are achieved through the unique design of the internal circuit. An onboard clock scheme is used to reduce the average operating current of the IC. During the operate phase the IC compares the actual magnetic field detected with the internally compensated switching points. The output Q is switched at the end of each operating phase. During the Standby phase the output stage is latched and the current consumption of the device reduced to some µA. The IC switching behaviour is omnipolar, i.e. it can be switched on with either the North or South pole of a magnet.
Micro power design
High sensitivity and high stability of the magnetic switching points
High resistance to mechanical stress
Programming pin for the switching direction of the output
Not suitable for automotive application
