TNY289PG ,AC to DC Converter, AC/DC Power Module - Power Integrations

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

79 points

Part No

TNY289PG
Manufacturer

Power Integrations
ChipWorker Part#

CW9943119
Category

AC to DC Converter, AC/DC Power Module
Package

DIP-8
Description

POWER INTEGRATIONS TNY289PG AC-DC Off-Line Switcher IC, TinySwitch-4 Family, Flyback, 85VAC - 265VAC, 25W, DIP-7
Documentation

Datasheet
Ships from

Moscow
Наличие

127 pcs In Stock
Estimated Price

$ 0.7

Buy TNY289PG

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TNY289PG Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TNY289PG Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TNY289PG
Manufacturer	Power Integrations
ChipWorker Part#	CW9943119
Category	AC to DC Converter, AC/DC Power Module
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	7 Pin
Case/Package	DIP-8
Power Rating	25 W
Breakdown Voltage	725 V
Number of Positions	7 Position
Output Power	32 W
Switching Frequency	124kHz ~ 140kHz
Duty Cycle	67 %
Input Voltage (Max)	265 VAC
Input Voltage (Min)	85 VAC
Input Voltage (AC Max)	265 v
Input Voltage (AC Min)	85 v
Output Voltage (Min)	50 VDC
Output Current (Max)	2.25 A
Maximum Duty Cycle	67 %
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	85VAC ~ 265VAC
	expand all
Size-Length	9.83 mm
Size-Width	6.6 mm
Size-Height	3.68 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The TNY289PG is an energy-efficient offline Switcher with line compensated overload power. TinySwitch-4 combines a high-voltage power MOSFET switch with a power supply controller in one device. Unlike conventional PWM controllers, it uses a simple ON/OFF control to regulate the output voltage. The controller consists of an oscillator and enables circuit (sense and logic), current limit state machine, 5.85V regulator, BYPASS/MULTIFUNCTION pin undervoltage, overvoltage circuit and current limit selection circuitry, over-temperature protection, current limit circuit, leading edge blanking and a 725V power MOSFET. TinySwitch-4 incorporates additional circuitry for line undervoltage sense, auto-restart, adaptive switching cycle on-time extension and frequency jitter. The drain pin is the power MOSFET drain connection. It provides internal operating current for both start-up and steady-state operation.
Line compensated overload power - No additional components
Dramatically reduces max overload variation over universal input voltage range
Simple ON/OFF control, no loop compensation needed
Selectable current limit through BP/M capacitor value
Higher current limit extends peak power/in open frame, maximum continuous power
Allows optimum TinySwitch-4 choice by swapping devices with no other circuit redesign
Maximizes MOSFET and magnetic utilization
ON-time extension - Extends low-line regulation range/hold-up time to reduce input bulk capacitance
Self-biased - No bias winding or bias components
Frequency jittering reduces EMI filter
Pin-out simplifies heat sinking to the PCB
SOURCE pins are electrically quiet for low EMI
Accurate hysteretic thermal shutdown protection with automatic recovery eliminates need for reset
Output overvoltage shutdown with optional Zener
Fast AC reset with optional UV external resistor
Very low component count enhances reliability and enables single-sided printed circuit board layout
High bandwidth provides fast turn-ON with no overshoot and excellent transient load response
Extended creepage between DRAIN and all other pins improves field reliability
Easily meets all global energy efficiency regulations
ON/OFF control provides constant efficiency down to very light loads
