TPS71202DRCT ,Voltage Regulator - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

103 points

Part No

TPS71202DRCT
Manufacturer

TI
ChipWorker Part#

CW38537064
Category

Voltage Regulator
Package

VSON-10
Description

Dual Channel LDO Dual 250mA Output, UltraLow Noise, High PSRR Low Dropout Linear Regulator LDO Regulator Pos 1.2V to 5.5V 0.25A 10Pin VSON EP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.65

Buy TPS71202DRCT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

TPS71202DRCT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

TPS71202DRCT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	TPS71202DRCT
Manufacturer	TI
ChipWorker Part#	CW38537064
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	VSON-10
Number of Outputs	2 Output
Input Voltage (DC)	5.50V (max)
Output Voltage	1.2V ~ 5.5V
Output Current	250 mA
Number of Positions	10 Position
Power Dissipation	1.92 W
Quiescent Current	300 µA
Output Capacitor Type	Ceramic
voltage rating	125 mV
Number of Regulated Outputs	2 Output
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.7 V
Output Current (Max)	0.25 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1920 mW
Accuracy	3 %
Input Voltage	2.7V ~ 5.5V
	expand all
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15

Similar & Replacement Parts

Similar products

Product Description

The TPS71202DRCT is an adjustable low-dropout (LDO) Voltage Regulator tailored to noise-sensitive and RF applications. This device features dual 250mA LDOs with ultralow noise, high power-supply rejection ratio (PSRR) and fast transient and start-up response. The regulator output is stable with 2.2µF ceramic output capacitors and features very low-dropout voltages. This regulator achieves fast start-up times while consuming very low quiescent current. When the device is placed in standby mode, the supply current is reduced to less than 0.3µA typical. This regulator exhibits approximately 32µRMS of output voltage noise with VOUT = 2.8V and a 0.01µF noise reduction (NR) capacitor. Applications with analog components that are noise-sensitive such as portable RF electronics will benefit from high PSRR, low noise and fast line and load transient features.
Excellent load/line transient response
Independent enable pins
Thermal shutdown and independent current limit
60µs Fast start-up time
Green product and no Sb/Br
