1727010 ,Terminal Block, Connector Terminal - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

191 points

Part No

1727010
Manufacturer

Phoenix
ChipWorker Part#

CW2399610
Category

Terminal Block, Connector Terminal
Description

Terminal Block; 10A; 160V; 3.81mm; 26 to 16AWG; 2; Screw; Solder; 2.5kV
Documentation

Datasheet
Ships from

Moscow
Наличие

1007 pcs In Stock
Estimated Price

$ 0.38

Buy 1727010

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

1727010 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

1727010 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	1727010
Manufacturer	Phoenix
ChipWorker Part#	CW2399610
Category	Terminal Block, Connector Terminal
Documentation	Datasheet
Mounting Style	Through Hole
Pin Pitch	3.81 mm
Number of Contacts	2 Contact
Wire Gauge	16AWG ~ 30AWG
Voltage Rating (AC)	160 V
Current Rating	10 A
Number of Rows	1 Row
Number of Circuits	2 Circuit
Flammability Rating	UL 94 V-0
Number of Positions	2 Position
Current Rating (Max)	13.5 A
Operating Temperature (Min)	-40 ℃
Voltage Rating (Max)	200 V
Voltage Rating	300 V
Operating Voltage (Max)	200 V
	expand all
Size-Length	7.61 mm
Size-Width	7.3 mm
Size-Height	8.5 mm
Housing Color	Green
Color	Green
Material	Nylon
Insulation Material	Nylon
Housing Material	Nylon
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HTS Code	8536904000
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The 1727010 is a 2-way Wire-to-board PCB Terminal Block made of PA insulation that allows connection of two conductors. The MKDS 1/ 2-3,81 has extremely small design for the respective conductor cross section. It features screw connection with tension sleeve and wave soldering.
Green color
Well-known connection principle allows worldwide use
UL94V-0 Flammability rating
Low temperature rise, maximum contact force
