1N5819RLG ,Schottky Diode - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

223 points

Part No

1N5819RLG
Manufacturer

ON Semiconductor
ChipWorker Part#

CW5293463
Category

Schottky Diode
Package

DO-41
Description

Diode Schottky 40V 1A 2Pin DO-41 T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

14130 pcs In Stock
Estimated Price

$ 0.07

Buy 1N5819RLG
